BMW 8 series Gran Coupe 840i M Sport 4dr Auto

Driver Aids

Servotronic system:

Drive experience control with Sport, Comfort, Eco Pro and Adaptive modes:

Driver Information

Check control system:

On board computer:

Service interval indicator:

Head up Display:

Outside temperature display:

BMW Teleservices:

Oil sensor for level and grade:

BMW legal emergency call:

Condition based service:

Brake pad wear indicator:

Integrated owners handbook:

BMW ConnectedDrive online services:

iDrive controller with shortcut buttons:

Light on warning:

BMW Live cockpit professional with 12.3" instrument display:

Security

Locking wheel bolts:

Centre lock switch:

Comfort access system:

Closing system with central locking:

Alarm system (Thatcham 1) with electronic engine immobiliser:

Vehicle key with exclusive M designation:

Safety

Side impact protection:

Warning triangle and first aid kit:

Child locks on rear doors:

3x3 point rear seatbelts:

Tyre pressure monitoring system (TPMS):

Active protection:

Crash sensor activating central locking release, hazard warning lights, fuel cut off, interior lighting, safety battery terminal clamp and airbags:

Front three point with pyrotechnical belt latch tensioner seat belts, belt force limiter and belt stopper:

Rear three point with pyrotechnical belt latch tensioner seat belts and belt force limiter:

Airbags - Driver and front passenger airbag with seat occupancy detection, knee, side and front passenger seat airbag deactivation:

Head airbags for 1st and 2nd seat row:

ISOFIX child seat mounting for the two outer rear seats:

Seats

50/50 split folding rear seat:

2 rear head restraints:

5 seats:

Front and rear seat heating:

Interior Features

Front door pockets:

Lockable glove compartment with light:

2 cup holders in front:

Steering column with adjustable height and length and activation via control on the steering column:

BMW ID:

Lashing eyelets:

Through loading function:

3 spoke M sport leather multifunction steering wheel with shift paddle:

1 x 12V power socket in front centre console:

Storage compartment under front centre armrest with light, 1 x 12V power socket and USB:

Body Glass

Heated windscreen washer jets:

Climate comfort windscreen:

Sun protection glass:

Thermally insulated windscreen:

Heat protection, sun protection glazing:

Front electric windows:

Automatic windscreen wipers and automatic headlight:

Rain sensor and automatic driving lights control:

Heated rear window, glass:

Brakes

ABS/EBD:

DSC - Dynamic Stability Control:

Cornering brake control (CBC):

Dynamic brake control:

Dynamic Traction Control - DTC:

Hill start assist:

Integrated brake system:

Electromechanical parking brake with automatic drive away release and auto hold function:

Brake discs, compound structure:

Interior Lights

Front reading lights:

Front entry lights doors:

Interior lighting - Interior light front centre above interior mirror,luggage compartment light,automatic interior light system soft on/soft off:

Ambient light with dynamic interior light:

Driver Convenience

Engine start/stop button:

Electric bootlid:

Automatic tailgate operation, remote opening with key, closing by tailgate button or remote control including tailgate in LED technology:

Exterior Lights

High beam assistant:

Dynamic brake lights:

LED rear lights:

Welcome lights in interior and door handle area:

Follow me home headlight function:

Third LED technology brake light in rear window:

Daytime driving lights front and rear active:

Entertainment

DAB Digital radio:

Favourite buttons:

Heating/Cooling/Ventilation

4 zone control automatic air conditioning:

Microfilter and active carbon filter:

Engine

Sport exhaust system:

Petrol Particulate Filter:

Exterior Body Features

Illuminated door handles:

Front and rear bumper system with replaceable deformation elements:

Carbon core:

Rear side wing doors:

Rear boot:

Front ornamental grille with kidney grille bars:

Side window graphic in black high gloss:

Illuminated radiator grille iconic glow:

Model logo - right tailgate in chrome, M emblem on side panel in light chrome, badge on bonnet and tailgate:

Chassis/Suspension

Adaptive M suspension:

Double wishbone front axle:

Dynamic Damper Control:

Communication

Wi-Fi hotspot:

Bluetooth hands free facility with USB audio interface, voice control and enhanced bluetooth + Wireless charging:

Transmission

M Sport differential:

Eight speed sport automatic transmission:

Driving Mirrors

Frameless interior mirror:

Exterior mirrors - Floating design mirror, electric adjust/heated/folding, aspherical:

Packs

Connected professional pack - 8 Series:

M sport exterior styling aerodynamics pack - 8 Series:

Vanity Mirrors

Front sun visors with ticket holder and illuminated mirror:

Embellishment Trims

Instrument and upper door panel in black walknappa leather with contrast stitching:

Weight and Capacities

Minimum Kerbweight: 1815

Gross Vehicle Weight: 2435

Fuel Tank Capacity (Litres): 68

Max. Loading Weight: 620

Luggage Capacity (Seats Up): 440

No. of Seats: 5

Max. Roof Load: 75

Luggage Capacity (Seats Down):

Turning Circle - Kerb to Kerb: 12.3

Vehicle Dimensions

Length: 5082

Width: 1932

Wheelbase: 3023

Width (including mirrors): 2137

Height: 1407

Height (including roof rails): 0

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies:

WLTP - MPG - Low: 22.8

WLTP - MPG - Medium: 32.5

WLTP - MPG - High: 38.2

WLTP - MPG - Extra High: 35.3

WLTP - MPG - Comb: 33.2

WLTP - MPG - Comb - TEL: 33.2

WLTP - MPG - Comb - TEH: 32.8

WLTP - FC (l/100km) - Low: 12.4

WLTP - FC (l/100km) - Medium: 8.7

WLTP - FC (l/100km) - High: 7.4

WLTP - FC (l/100km) - Extra High: 8

WLTP - FC (l/100km) - Comb: 8.5

WLTP - FC (l/100km) - Comb - TEL: 8.5

WLTP - FC (l/100km) - Comb - TEH: 8.6

Performance

0 to 62 mph (secs): 5.4

Top Speed: 155

Engine Power - BHP: 333

Engine Power - PS: 1

0 to 60 mph (secs):

Engine Power - KW: 245

Engine Power - RPM: 5500

Engine Torque - LBS.FT: 369

Engine Torque - NM: 500

Engine Torque - RPM: 1700

Engine Torque - MKG: 51

Engine and Drive Train

Cylinders - Bore (mm): 82

Cylinders - Stroke (mm): 94.6

CC: 2998

Cylinders: 6

Cylinder Layout: IN-LINE

Number of Valves: 24

Camshaft: DOHC

Fuel Delivery: TWIN TURBO

Catalytic Convertor: 1

Engine Layout: NORTH SOUTH

Compression Ratio: 11.0:1

Transmission: SEMI-AUTO

Gears: 8 SPEED

Engine Code: B58B30M1

General

Coin Series: M Sport

Coin Description: i

Standard manufacturers warranty - Years: 3

Standard manufacturers warranty - Mileage: 999999

Safety Concerns?:

Special Edition:

Special Order:

Based On ID: 0

Insurance Group 1 - 50 Effective January 07: 45E

NCAP Adult Occupant Protection %: 0

NCAP Child Occupant Protection %: 0

NCAP Pedestrian Protection %: 0

NCAP Safety Assist %: 0

NCAP Overall Rating - Effective February 09: 0

Badge Power: 333

Badge Engine CC: 3

Vehicle Homologation Class: M1

Generation Mark: 2

Alternative Fuel Qualifying:

Tyres

Tyre Size Front: 245/35 R20

Tyre Size Rear: 275/30 R20

Tyre Size Spare: RUN FLAT TYRES

Wheel Type: 20" ALLOY

Wheel Style: Y SPOKE STYLE 728M

Alloys?: 1

Space Saver?:

Emissions - ICE

Standard Euro Emissions: EURO 6

Noise Level dB(A): 67

HC+NOx:

WLTP - CO2 (g/km) - Low: 283

WLTP - CO2 (g/km) - Medium: 198

WLTP - CO2 (g/km) - High: 168

WLTP - CO2 (g/km) - Extra High: 183

WLTP - CO2 (g/km) - Comb: 195

WLTP - CO2 (g/km) - Comb - TEH: 196

WLTP - CO2 (g/km) - Comb - TEL: 194

Test Cycles

Emissions Test Cycle: WLTP

RDE Certification Level: RDE 2

Emissions - Lifecycle

End-of-Life Emissions - CO2e (Equivalent) - tonnes: 0.5

In-Life Emissions - CO2e (Equivalent) - tonnes: 35.2

Lifetime Emissions - CO2e (Equivalent) - tonnes: 44.9

Production Emissions - CO2e (Equivalent) - tonnes: 9.2
