Jeep Compass SUV 1.3 T4 GSE 4xe PHEV Trailhawk 5dr Auto

Seats

Heated front seats:

3 rear seat head restraints:

Front head restraints:

Child seat anchorage points:

60/40 split folding rear seat:

Driver seat memory function:

3 seat bench in 2nd row:

Fold flat front passenger seat:

Centre rear 3 point seat belt:

Front seats back map pockets:

Power 2-way driver lumbar adjustment:

Driver seat 6 way manual adjust:

6 way manual adjust front passenger seat:

Front height-adjust seatbelts:

Single front passenger seat:

Easy To Clean Seat:

Safety

Front passenger airbag:

Front side airbags:

Tyre pressure monitoring display:

Dual note electric horns:

Rear seat belt reminder:

Dual tyre pressure - turn changes:

Driver's front airbag:

Passenger airbag deactivation switch:

Front and rear side curtain airbags:

Electrical steering column shaft lock:

Rear door child protection locks:

Jeep call assistance label:

Body Glass

Heated rear window:

Rain sensitive windscreen wipers:

Deep tint privacy glass:

Power windows - driver and passenger express up/down:

Rear windshield washer/wiper:

Windshield wiper de-icer:

Driver Information

Tachometer:

Outside temperature display:

Vehicle information centre:

Media centre electronic storage:

Instrument panel:

Drowsy driver detection:

TBM - Connected services (e-call):

Instrument cluster- 10.25" TFT Colour display:

160 MPH primary speedometer:

English owners handbook:

United Kingdom equipment group:

Extended Guide in English:

Exterior Body Features

Body colour door handles:

Black window surrounds:

Removable short mast antenna:

UK front number plate bracket:

Lower bodyside cladding in black:

Compass badge:

Trail rated badges:

Rear fascia:

Jeep badge:

Black side roof rails:

Trailhawk hood decal:

Exterior door mirrors with heating element:

Front fascia/belly pan skid plate:

Belly pan - underbody protection:

Coastdown and run-in optimization:

Skid plate shield - transmission:

Skid plate shield - fuel tank:

Skid plate shield - transfer case:

Skid plate shield - front suspension:

Neutral grey exterior accents:

Accent/body colour bumpers:

Rear side wing doors:

4XE badge/e-Hybrid badge:

Carry back MHEV:

Off road bumper:

Partial body cover protection:

Trailhawk badges:

Gloss Black Grille - Gloss Black Crosshairs:

Rear Jeep Badge:

Trail Rated:

Chromed DLO:

Higher ground clearance:

Entertainment

6 speakers:

Steering wheel mounted audio controls:

DAB Digital radio:

Bluetooth audio streaming:

USB host flip:

USB A and C type - second row:

Global telematics box module (TBM):

Media hub (USB A-C TYPE):

Wireless CarPlay/Android Auto:

Interior Features

Cloth/vinyl upholstery:

Coat hooks:

Heated steering wheel:

Overhead console:

Tilt/telescopic steering column:

Passenger assist handles:

Full length centre console:

Cargo tie down loops:

Centre console with sliding armrest:

Spare wheel storage insulation:

12V auxiliary power outlet - 2nd row:

Cargo load floor:

Dash insulation:

Glovebox with damped soft close door:

Driver assist handle:

Internal rear grab handles:

Rear seat armrest with cupholder:

Vinyl wrap steering wheel:

Leather wrapped gear knob:

No Alternator:

Height adjustable cargo load floor:

Driving Mirrors

Aspherical driver's exterior mirror:

Auto dimming rear view mirror:

Gloss black exterior door mirrors:

Door mirrors: power adjustable and folding, heated with auto folding function and indicators:

Exterior Lights

Automatic headlights:

Third brake light:

Rear fog lamps:

Daytime running lights:

LED tail lights:

LED rear lights:

Auto high beam:

LED front fog lamps:

Headlamp off time delay:

Smartbeam headlights:

Neutral gray headlamp bezels:

Headlamp leveling system:

LED projector headlamps:

Brakes

Electronic stability control:

Hill descent control:

Electronic parking brake:

Hill start assist:

Energy recovery system:

All speed traction control:

Rain brake support:

AEB with pedestrian and cyclist detection:

Automatic electronic hold brake:

Driver Aids

Electric power steering:

Adaptive cruise control with Stop and Go:

Intelligent speed assist:

Active speed limiting device:

Traffic sign recognition (TSR):

Selec terrain system with sport mode:

Full speed forward collision warning plus mitigation:

Active lane management:

Parksense front and rear park assist system:

Parallel and perpendicular park assist with exit:

Interior Lights

Cargo area lights:

Glovebox light:

Illuminated door entry system:

Front map reading lights:

Interior door handle LED lamps:

Front map pocket LED lamps:

Overhead dome LED lamps:

Vanity Mirrors

Sunvisors with illuminated vanity mirrors:

Engine

Battery run - down protection:

Battery skid plate:

E- launch:

Electric drive:

E-creeping:

E-Parking:

E-Queueing:

CO2 improvement:

Security

Premium security alarm:

Capless fuel filler:

Occupant detection system:

Passive entry and keyless go (Key fob without panic button):

Power locking fuel filler door:

Chassis/Suspension

Off road suspension:

Electronic roll mitigation:

Towing

Trailer sway damping:

Red rear tow hook:

Communication

E-call:

Wireless charging pad:

Carpets/Rugs

Cargo compartment organiser:

Cargo compartment carpet:

Cargo compartment cover:

All weather floormats with Jeep logo:

Cargo compartment reversible mat:

Embellishment Trims

Front and rear air vents:

Speakers in satin chrome silver:

Heating/Cooling/Ventilation

Rear air conditioning and heater vents:

Dual zone temperature control with preconditioning capability and heater:

Vehicle Charging

Mode 3 cable:

Wheels - Spare

No fix and go kit:

Service/Warranty

UK Warranty:

Wheels - Alloy

17" diamond cut painted high gloss black alloy wheels:

Packs

Ventilated leather seats - Compass Trailhawk:

Weight and Capacities

Minimum Kerbweight: 1860

Gross Vehicle Weight: 2475

Fuel Tank Capacity (Litres): 36.5

Max. Towing Weight - Braked: 1250

Max. Towing Weight - Unbraked: 600

Max. Loading Weight: 615

Luggage Capacity (Seats Up): 420

No. of Seats: 5

Max. Roof Load: 68

Luggage Capacity (Seats Down): 1230

Turning Circle - Kerb to Kerb: 11.1

Vehicle Dimensions

Length: 4398

Width: 1874

Wheelbase: 2636

Width (including mirrors): 2033

Height: 1659

Height (including roof rails): 1664

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies:

Performance

0 to 62 mph (secs): 7.3

Top Speed: 124

Engine Power - BHP: 240

Engine Power - PS: 1

0 to 60 mph (secs):

Engine Power - KW: 177

Engine Power - RPM: 5750

Engine Torque - LBS.FT: 199

Engine Torque - NM: 270

Engine Torque - RPM: 1850

Engine Torque - MKG: 27.5

Engine and Drive Train

Cylinders - Bore (mm): 70

Cylinders - Stroke (mm): 86.5

CC: 1332

Cylinders: 4

Cylinder Layout: IN-LINE

Number of Valves: 16

Camshaft: DOHC

Fuel Delivery: TURBO DIRECT INJECTION

Catalytic Convertor: 1

Engine Layout: FRONT TRANSVERSE

Compression Ratio: 10.5:1

Transmission: AUTO

Gears: 6 SPEED

General

Coin Series: Trailhawk

Coin Description: T4 GSE 4xe PHEV

Standard manufacturers warranty - Years: 3

Standard manufacturers warranty - Mileage: 60000

Safety Concerns?:

Special Edition:

Special Order:

Based On ID: 0

Insurance Group 1 - 50 Effective January 07: 31E

Service Interval Mileage: 9000

Service Interval Frequency - Months: 12

Timing Belt Interval Mileage: 0

Timing Belt Interval Frequency - Months: 0

NCAP Adult Occupant Protection %: 0

NCAP Child Occupant Protection %: 0

NCAP Pedestrian Protection %: 0

NCAP Safety Assist %: 0

NCAP Overall Rating - Effective February 09: 0

Badge Power: 240

Badge Engine CC: 1.3

Vehicle Homologation Class: M1

Generation Mark: 2

Alternative Fuel Qualifying: 1

Tyres

Tyre Size Front: 235/60 R17

Tyre Size Rear: 235/60 R17

Tyre Size Spare: N

Wheel Type: 17" ALLOY

Wheel Style: N

Alloys?: 1

Space Saver?:

Emissions - ICE

Standard Euro Emissions: EURO 6

CO: 0.151

HC+NOx:

Particles:

Electric Vehicle Data

Battery Charging Scenario 1 - Charge Time (Mins): 300

Battery Charging Scenario 1 - Power Supply - kW: 2.3

Battery Charging Scenario 1 - Percentage Change: 0-100

Battery Charging Scenario 2 - Charge Time (Mins): 0

Battery Charging Scenario 2 - Power Supply - kW:

Battery Charging Scenario 2 - Percentage Change: N

Battery Charging Scenario 3 - Charge Time (Mins): 0

Battery Charging Scenario 3 - Power Supply - kW:

Battery Charging Scenario 3 - Percentage Change: N

Battery Charging Scenario 4 - Charge Time (Mins): 0

Battery Charging Scenario 4 - Power Supply - kW:

Battery Charging Scenario 4 - Percentage Change: N

Coupler/Connector Type: Type 2

Standard manufacturers Battery warranty - Years: 8

Standard manufacturers Battery warranty - Mileage: 100000

Battery Capacity in kWh: 11.4

Battery Leased:

Battery Type: Lithium-ion

WLTP - Equivalent AER (km) - City: 52

WLTP - Equivalent AER (km) - Comb: 47

WLTP - Equivalent AER (km) - Comb - TEL: 47

WLTP - Equivalent AER (km) - Comb - TEH: 47

WLTP - Equivalent AER (miles) - City: 32

WLTP - Equivalent AER (miles) - Comb: 29

WLTP - Equivalent AER (miles) - Comb - TEH: 29

WLTP - Equivalent AER (miles) - Comb - TEL: 29

Battery Capacity % guaranteed under warranty: 70

Charging Port Location: Left Side Rear

Usable Battery Capacity: 11.4

Maximum Charging Rate - kW: 2.3

Test Cycles

Emissions Test Cycle: WLTP

RDE Certification Level: RDE 2

Emissions - PHEV

WLTP - CO2 Weighted (g/km) - Comb: 43

WLTP - CO2 Weighted (g/km) - Comb - TEL: 42

WLTP - CO2 Weighted (g/km) - Comb - TEH: 43

Fuel Consumption - PHEV

WLTP - FC Weighted (l/100km) - Comb: 2

WLTP - FC Weighted (l/100km) - Comb - TEL: 1.8

WLTP - FC Weighted (l/100km) - Comb - TEH: 2

WLTP - FC Weighted (mpg) - Comb: 141.2

WLTP - FC Weighted (mpg) - Comb - TEL: 156.9

WLTP - FC Weighted (mpg) - Comb - TEH: 141.2
